Characteristics Of Machine Tool
  • Characteristics Of Machine Tool

Characteristics Of Machine Tool

1. The structure of the bed is stable and can bear the inertia caused by high speed motion.
2. The column adopts "herringbone" design to improve overall rigidity and minimize themmal deformation.
3. Precision high speed mute imported ball screw, improve the accuracy of machine tool.
4. The imported heavy load linear slide rail is adopted to make the machine tool move smoothly and position accurately.
5. Equipped with Taiwan original 24T tool magazine, suitable for the processing of complex parts.
6. The imported spindle provides the cutting rigidity of the machine tool, high speed cutting stability and high efficiency.
7. Two spindles can be machined at the same time, so the machining efficiencyis higher.

PREV: No previous article Next: CNC Engraving And Milling Machine
Project Unit DVMC1160 DVMC1370
Work table
Table size mm 1200x600 1400x700
Table T-slot mm 5-18x100 5-18x110
Maximum load of workbench kg 1000 1200
Processing range
X-axis travel (leftand right) mm 1100 1300
Y-axis travel(frontand rear) mm 600 700
Z-axis travel (up and down) mm 600 700
Number of Z-axes 2 2
Distance from spindle nose to work bench mm 120-720 120-820
Distance from spindle center to column rail surface mm 660 770
Spindle
Spindle number 2 2
Spindle center distance (customizable) 550±0.05 650±0.05
Maximum spindle speed (belt/direct connection) rpm 8000/12000 8000/12000
Spindle power KW 11/15 11/15
Taper of spindle bore BT40 BT40
Feed drive
G00 rapid feed (X/Y/Z axis) m/min 32/32/32 32/32/32
G01 cutting feed mm/min 1-10000 1-10000
Servo motor specifications N.m 22/22/22B 22/22/22B
Ball screw specifications mm 4012 4012
three-axis fast moving speed three-wire
Tool magazine
Tool magazine form / Disk manipulator type
Magazine capacity PCS 24 24
Maximum tool diameter (full tool/blank） Φ75/Φ150 Φ120/Φ200
Maximum tool length 8 18
Maximum weight of cutter 300 300
Tool change time (tool to tool) 2.2 2.2
Accuracy
Positioning accuracy mm 0.005/300 0.005/300
Repeat positioning accuracy mm 0.003/300 0.003/300
Other
Air pressure kg/cm2 6.5 6.5
Oil Capacity L 4 4
Power capacity kw 35 45
