Cnc Gantry Friction Stir Welding Series
  • Cnc Gantry Friction Stir Welding Series

Cnc Gantry Friction Stir Welding Series

Application Field
Aviation, aerospace, ships, rail transit, newenergy vehicles New energy battery tray, water-cooled box, aluminum alloy motor housing Electronic power (radiator, heat sink, etc.)
Small parts
Aluminum alloy products welding

PREV: VKC Series Recutting Moving Column Planer Type Strip Machining Center Next: Gantry Boring And Miluing Machine Series
Project/Model Unit TP-1580FSW TP-2012FSW TP-2515FSW TP-3018FSW TP-4020FSW
Welding materials - Aluminum, copper, steel, titanium
Welding ability - Aluminu alloy 1~8mm Aluminu alloy 2~16mm Aluminu alloy 2~16mm Aluminu alloy 3~25mm Aluminu alloy 3~25mm
Weld form - Flat seam, flat two-dimensional curve
Working desk size (LxW) mm 1500x800 2000x1200 2500x1500 3000x1800 4000x2000
Gantry width mm 1200 1500 1800 2200 2500
Welding space mm 0-350 0-450 0-600 0-800 0-900
Welding stroke X axis mm 1300 1800 2300 2800 3800
Y axis mm 700 1100 1400 1700 1900
Z axis mm 300 350 400 600 700
B axis mm ±5° ±5° ±5° ±5° ±5°
C axis mm Nx360° Nx360° Nx360° Nx360° Nx360°
Speed of work X axis mm/min 8000 8000 6000 6000 6000
Y axis mm/min 8000 8000 3000 3000 3000
Z axis mm/min 4000 4000 1500 1500 1500
Spindle speed rpm 2500 2500 2000 2000 1500
Equipment size L mm 5100 6100 7300 8500 10800
W mm 3000 3200 3800 4200 4500
H mm 3200 3400 3800 4000 4100
Control system - Taiwan Baoyuan (optional)
